SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 31
6 MAINTENANCE
6.1 Replacing media packs
Switch the unit off by pressing the STOP button.
Leave the unit to stand for 30 seconds to relieve any internal pressure.
Open the front door cover to expose the media packs.
Press down the black lever on top of the cartridge and pull it away from the
retainer block.
Discard the media Pack and remove the new pack from its bag removing the
two black plugs from the inlet/outlet ports.
Insert the media pack into the unit locating it in the media retaining block,
push it home until it clicks into position and retaining mechanism clicks up.
Press “START” and follow the instructions on screen for setting new pack
replacement date
After resetting pack date the unit can be started from the power on screen.
6.2 Cleaning inlet screen filter
It is recommended that this filter is cleaned at least once per year.
The inlet screen filter is located in the right hand side of the unit.
Switch off the water supply at source
To relieve any residual water pressure, momentarily switch the unit on
then off.
Remove the side panel of the unit.
o To do so, first remove the front cover by pulling it gently from the
unit using the hand holds provided.
o Pull the pod assembly gently forward to disengage the top cover
retaining pin.
o Remove the top cover by lifting up at the front and sliding it gently
backwards.
o Remove the four retaining screws holding the side panel in place
and slide gently backwards.
