SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954
39
8 INSTALLATION
Using the installation kit provided observe the following procedure to make your
Select HP ready for use.
8.1 Installation Kit
The installation kit comprises
Contents:
3 metres ½” Blue hose,
7 metres 8mm nylon tubing,.
1 off Jubilee clip.
3 metres ,12mm nylon tubing,.
1 off 12mm stem elbow.
3 off 8mm stem elbows.
8.2 Media Packs Media Packs
Your Select HP is supplied with two different media cartridge packs which are
available in two sizes depending on your unit capacity.
A Pretreat pack and Puripac cartridge. Size 8 for unit types 40,80,160 and
size 16 for unit type 320.
The Select HP must be fitted with a Pretreat pack PT8/PT16 and a Puripac
PP8 or P16.
The Puripac must be fitted in the right hand position and the Pretreat cartridge
in the left hand position when viewed from the front.
Refer to Section 6.4, Maintenance and service spares, for re-ordering details.
