SELECT HP USER INSTRUCTIONS
Issue: A, part number L300954 41
Wall Mounted
Use a wall mount bracket (Part Number L300900 shown below)
Secure the bracket to a suitable wall. Careful consideration should be
given to the strength and suitability of the wall as the working weight of the
Select HP is 50Kg.
Secure the bracket to the wall. Remove the feet of the HP by unscrewing
them. Place the HP on the wall bracket and fix to the bracket using screws
through the feet mounting points.
Hose Connections
All hoses are connected to the unit via its push fit
connectors. To make a connection, the hose is
simply pushed in by hand; the unique patented
locking system then holds the tube firmly in place
without deforming it or restricting flow.
Cut the tube square and push in until the tube
stops.
Ensure the tube is pushed into the tube stop,
securing tube in position.
To remove tubing push collet against body and
slide tube out of fitting
Water Inlet connection: Fit 8mm tubing to the water
inlet connector found on the rear of the unit and the
other end to your water supply.
