1.2. Parameters table
Table 1. Parameters of USR-G816
USR-G816 specifications
Cellular
Interface
Frequency
5G NR sub-6 GHz (3GPP Rel-16)
Band(NA/NSA):
n1/2/3/5/7/8/12/13/14/18/20/25/26/28/29/30/38/40/41/48/66/70/71/75/76/77/78/ 79;
4G LTE (CAT 19 DL / CAT 18 UL)
LTE-FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/32/66/71;
LTE-TDD: B34/38/39/40/41/42/43/48;
LAA: B46;
3G WCDMA: B1/2/4/5/8/19
Maximum Transmission
Data Rate
5G SA Sub-6: Max. 2.4Gbps (DL)/Max. 900Mbps (UL);
5G NSA Sub-6: Max. 3.4Gbps (DL)/Max. 550Mbps (UL)
LTE-FDD: Max. 1.6Gbps (DL)/Max. 200Mbps (UL)
WCDMA: Max. 42 (DL)/Max. 5.76 (UL)
Antennas
4 × SMA-K Connectors (Center PIN: SMA Female)
SIM Slot
2 x (3 V/1.8 V) mini-SIM(2FF) Push-push type slot (SIM Card 2 can be configured with built-in
eSIM)
Ethernet Interface
WAN
1 x WAN port (can be configured as LAN) 10/100/1000 Mbps, compliance with IEEE 802.3,
IEEE 802.3u, supports auto MDI/MDIX crossover, Ethernet Isolation 1.5 KV RMS
LAN
3 x RJ45 port, 10/100/1000 Mbps, supports auto MDI/MDIX crossover, Ethernet Isolation 1.5
KV RMS
Indicators
PWR
red, always on after powered on
WORK
green, blinking every 1second when the router is ready and working properly
NET
Mobile network type LEDs
NET lights on after device is connected to the network. Green stands for 5G, green and red
for 4G, and red for 3G
SIG
Mobile signal strength indication LED
Green represents excellent signal, two-color light represents good signal, red represents
poor signal
WLAN
always solid on when WiFi is enabled and working properly
WAN
LED blinking When Connection established and data is being transferred over this port.
LAN
LED blinking When Connection established and data is being transferred over this port.
Wi-Fi Interface
Antennas
2 × SMA-K Connectors (Center PIN: SMA Female)
MIMO
2×2
Standards
Concurrent dual-band 802.11a/n/ac (5.8GHz) and 802.11b/g/n (2.4GHz)
Modes
AP/AP+STA/AP+WDS repeater
Data speed
Up to 1733Mbps wireless operation rate at 5.8GHz
Security
Wi-Fi security with WPA-PSK, WPA2-PSK, Mixed WPA/WPA2-PSK, WPA2-PSK+CCMP
Transmission distance
200 meters by line of sight. Actual transmission distance depends on environment of the
site.
GNSS(Optional)
Antenna
1 × SMA-K Connector (Center PIN: SMA Female)
Technology
GPS, GLONASS, BeiDou, Galileo
Protocol
NMEA 0183
Power Supply
Adapter
DC 12V/2A
Connector
DC Power Jack Barrel Type Female 5.5*2.1mm Round socket or industrial terminal
block(V+,V-),reverse polarity protection
