USR-G816 User Manual
pusr.com
1
- 8 -
WLAN
On: Enable WLAN
Off: Enable WLAN
GNSS
Used for GNSS version
NET
Green: 5G network
Orange: 4G network
Red: 3G network
1.4. Dimension
➢ Sheet metal housing, DIN-Rail mounting and wall mounting supported.
➢ 125.0*103.0*45.0mm (L*W*H, accessories not included)
Figure 1. Dimension of USR-G816
2. Get Started
2.1. Login router
Power on the G816 router, connect PC to USR-G816 via LAN port or via Wi-Fi, users can login router via
Chrome or the other browser. The default network parameters are shown in the following table:
Table 3. Default network parameters
Parameter
Default value
