SPECIFICATION
GENERAL
Power Supply Requirements : DC 12 Volts, Negative Ground
Chassis Dimensions : 7" (W) x 6.2" (D) x 3.9"(H)
Tone Controls
- Bass (at 100 Hz) : ±10 dB
- Treble (at 10 kHz) : ±10 dB
Maximum Output Power
- Version V : 4x60 watts
Current Drain
- Version V : 15 Ampere (max.)
RADIO
(U.S.A)
FM
Frequency Coverage 87.5 to 108 MHz
IF 10.7 MHz
Sensitivity (S/N=30dB) 4μV
Stereo Separation >25dB
AM
Frequency Coverage 520 to 1710kHz
IF 450kHz
Sensitivity (S/N=20dB) 38dBu
