Pyle PLTS78DUB User Manual

www.PyleUSA.com
10
1. OPEN /
Briey press to slide the monitor out of slot or slide the monitor inside of slot.
Press and hold this button to tilt up and down the monitor.
2. Power ON/OFF, MODE
Press it to turn the unit ON , press and hold to turn the unit OFF.
During power on, press it briey to select between RADIO, DISC, USB, SD, AUX IN,
AV IN and BT. 3 & 7. /
In Disc/USB/SD Playback mode, press for fast forward or fast backward playback.
In Radio mode, press to scan radio station step by step.
4. AS /
In Radio mode, press and hold AS for more than 2 seconds to store 18 FM stations
and 12 AM stations automatically. Press it briey to recall each preset station that
stored in memories in each band.
Press the button to make a call / receive a call / redial the last dialed phone
number.
5. (Play/Pause)
In Disc/USB/SD/BT music playback mode, press to pause playback. Press again to
start where playback stopped. 6 & 17. / . In Disc/USB/SD/BT music
playback, press both buttons to skip next or previous track. In Radio mode, press
to tune radio frequency down or up one step at a time.
8. TITLE
When playing a digital video, pressing this button will open the TITLE menu
which is recorded on the media. When playing a VCD disc, press this button to
create a PBC(Playback Control) menu for the disc to assist in making playback
selections.
9. RPT (Repeat playback) / 2
In Disc/USB/SD card playback mode, press to repeat playback. In radio mode,
press to store or recall the preset station 2.
10. DISP / 1
In video playing mode, press to show OSD menu. In radio mode, press to store
or recall the preset station 1.
11. AUDIO / 5
In Disc/USB/SD card playback mode, press for making changes to the way the
soundtrack is reproduced. In radio mode, press to store or recall the preset
station 5.
12. MENU / 4
In Disc/USB/SD card playback mode to display the root level directory of a
digital video disc. In radio mode, press to store or recall the preset station 4.
13 & 21. VOL+/VOL
Use these controls to adjust the volume level.
14. SEL
Press to turn to EQ settings. In Radio mode.
15. MUTE
In power on mode, press the MUTE button to toggle mute on or o.
16. BAND /
Press BAND to select between FM1, FM2, FM3, AM1 and AM2 bands.
In BT mode, press to reject an income call or end a call.

Pyle PLTS78DUB Specifications

General

MP3 playback	Yes
USB direct playback	No
Audio formats supported	MP3
Video formats supported	MPEG4
Supported radio bands	AM, FM
Preset stations quantity	30
Output power	320 W
Product color	Black
Ready for iPod	-
Disc types supported	CD, CD-R, CD-RW, DVD
Audio output channels	4.0 channels
Analog signal format system	NTSC, PAL
Aspect ratio	16:9
Display type	LCD
Display diagonal	7 \
Display brightness	400 cd/m²
Display resolution	1440 x 234 pixels
AV output	1
Compatible memory cards	MMC, SD
Number of optical discs	1 discs

Weight and Dimensions

Dimensions (WxDxH)	178.1 x 166.1 x 50.29 mm
