Pylontech Force-H1-V2 User Manual

8
Battery System
Discharge Current
(Amps, Standard)
14.8
Battery System
Discharge Current
(Amps, Normal)
37
Battery System
Discharge Current
(Amps, Max.@15s)
42
Short circuit rating
(Amps)
＜4000
Efficiency (%)
96
Depth of Discharge
(%)
95
Dimension(W*D*H,
mm)
600*380*
530
600*380*
700
600*380*
870
600*380*
1040
600*380*
1210
600*380*
1380
Communication
CANBUS/Modbus RTU
Protection Class
IP55
Weight (kg)
86
122
158
194
230
266
Operation Life (Years)
15+
Operation
Temperature(℃)
0~50℃
Storage
Temperature(℃)
-20~60℃
Altitude(m)
<2000
Humidity
5~95%
Product Certificate
VDE-AR-E 2510-50, IEC62619, IEC63056, IEC62040-1,
2014/53/EU(RED),UL1973
Transfer Certificate
UN38.3
1) Battery Controller
Dimensions (W*D*H)
600×380×150mm
2) Battery Module
Dimensions (W*D*H)
600×380×170mm
3) Battery bottom
base Dimensions
(W*D*H)
600×380×40mm
