Pylontech Force-H1-V2 - Installation and Operation Checklists

47
Annex 1: Installation and System Turn ON Progress List
Tick after
completion
No
.
Item
Remark
☐
1
The environment is meeting all technical requirements.
3.3.1 Cleaning
3.3.2 Temperature
3.3.3 Fire-extinguisher System
3.3.4 Grounding System
3.3.5 Clearance
Refer to chapter
3.3
☐
2
Selection of installation sites.
Refer to chapter
3.4.3.
☐
3
Battery base is installed follow the technical
requirements.
Refer to chapter
3.4.4.
☐
4
Battery modules installation.
Refer to chapter
3.4.5.
☐
5
Battery system are fixed.
Refer to chapter
3.4.6.
☐
6
Control Module (BMS) and Battery Module are
installed well.
Refer to chapter
3.4.7.
☐
7
Connect D+ and D- between BMS to the inverter/PCS
or confluence cabinet.
Refer to chapter
3.5.2.
☐
8
Connect the grounding cable.
Refer to chapter
3.5.1.
☐
9
Double check every power cables, communication
cables, grounding cable installed well.
Refer to chapter
3.5.2 and 3.5.1.
☐
10
Switch the external power or inverter/PCS on, ensure
all the power equipment can work normally.
Refer to chapter
3.6.4.
☐
11
The first installation should do full charging progress
automatically.
If the status LED of BMS turns to blue, it means this
battery string is operation.
