2.2.1.2 Multi-groups system parameter (Max. 6 groups per system)
For multi-groups operation, please make sure the battery type in the whole system is the same,
please make sure the battery amount of each group is the same.
Product Type
Force-H1-V2 in multi-groups
Battery System Voltage（Vdc）*
96/144 / 192 / 240 / 288 / 336
Battery System group amount(pcs)
2
3
4
5
6
Battery System capacity (AH)
148
222
296
370
444
Battery System Operation
Current(Amps, Standard)
29.6
44.4
59.2
74
88.8
Battery System Operation
Current(Amps, Normal)
74**
111**
148***
185***
222***
Battery System Operation Current
(Amps, Max.@15s)
84**
126**
168***
210***
252***
P-Combiner-HV-3/6 Operation
Current (Amps, Normal)
50
100
P-Combiner-HV-3/6 Operation
Current (Amps, Max.@15s)
80
160
*The Battery System Voltage is varying depends on battery amount in serial per group.
**The current is based on BMS theoretical operation current to consider. If use P-Combiner-HV-
3 as the combiner box of the multi-groups` battery system wiring connection, the max.
continuous operation current is 50Amps, max. peak operation current is 80Amps for 15sec. for
the battery system. Please make sure the real operation current not exceed the combiner box
power rating.
***The current is based on BMS theoretical operation current to consider. If use P-Combiner-
HV-6 as the combiner box of the multi-groups` battery system wiring connection, the max.
continuous operation current is 100Amps, max. peak operation current is 160Amps for 15sec.
for the battery system. Please make sure the real operation current not exceed the combiner
box power rating.
