10
2.2.1.2 Multi-strings System Parameters (Max. 6 Strings per System)
For multi-strings operation, please make sure:
the battery type in the whole system is the same;
the battery amount of each string is the same.
Force-H3 in multi-strings
Battery System Voltage(VDC)
204.8/307.2 / 409.6 /512 / 614.4 / 716.8
Battery System string amount(pcs)
Battery System capacity (Ah) 100 150 200 250 300
Battery System Operation
Current(Amps, Standard)
20 30 40 50 60
Battery System Operation
Current(Amps, Normal)
80 120 160 200 240
Battery System Operation Current
(Amps, Max.@15min)
110 165 220 275 330
P-Combiner 3/6-V2 Operation Current
(Amps, Normal)
50
100
P-Combiner 3/6 Operation Current
(Amps, Max.@15s)
80
160
*The Battery System Voltage varies depending on battery amount in serial per string.
**The current is based on BMS theoretical operation current. If using P-Combiner 3-V2 as the combiner box of the
multi-strings` battery system wiring connection, the max. continuous operation current is 50Amps, max. peak
operation current is 80Amps for 15 seconds. Please make sure the real operation current not exceed the combiner
box power rating.
The current is based on BMS theoretical operation current. If using P-Combiner 6-V2 as the combiner box of the
multi-strings` battery system wiring connection, the max. continuous operation current is 100Amps, max. peak
operation current is 160Amps for 15 seconds. Please make sure the real operation current not exceed the
combiner box power rating.
IMPORTANT,
DO NOT use P-Combiner-HV-3/6-V2 or similar concept of multi-strings connection method
in case the multiple battery strings need to be operated independently.
