Pylontech Force-H3 User Manual

13
2.2.3.2 Control Module Display Panel
LED Button
Button
Action
Instructions
Short Press Display the LED panel for 20sec.
Long Press 1
(about 5~10
secs)
(1) When System Status LED fast flashes blue , release the
button, then it is 115200 baud rate of RS485.
(2) When System Status LED fast flashes orange , release the
button, then it is 9600 baud rate of RS485.
(3) If a special protocol (except Pylontech Protocol) is selected,
follow ‘Long Press 2’, then the baud rate changing described
here is ineffective.
Long Press 2
(>10secs)
Communication Protocol Selection, for details please check with
Pylontech service team. Communication Protocol Selection
Guidance
Battery
Module
Status Light
LED Button
System
Status LED
System
Capacity
Status
