Pylontech Force-H3 User Manual

29
3.4.6 Installation of the Battery Module onto the Base
Warning: Single battery module is 39kg. The battery module must be handled by more
than 2 personnel if there’re no handling tools.
3.3.1.1 Lift the two handles on the battery module as blow, making sure the battery not tilting to one
side.
3.3.1.2 Adjust to keep the connector of the battery (circled in red) align with the connector of the
base (circled in red). Slowly put down the battery, fitting it properly onto the base.
3.3.1.3 Continue to install the left battery modules one by one onto the existing battery.
NOTE : Max. 7 battery modules to be installed in one system.
1
2
3
