Annex 1: Installation and System Power On Process List
Tick after
completion
No
.
Item
Remark
1
The environment is meets all technical
requirements.
3.3.1 Cleaning
3.3.2 Temperature
3.3.3 Fire-extinguisher System
3.3.4 Grounding System
3.3.5 Clearance
Refer to section 3.3
2
Selection of installation sites.
Refer to section 3.4.3.
3
Battery base is installed follow the technical
requirements.
Refer to section
3.4.5.
4
Battery modules installation.
Refer to section
3.4.6.
5
Battery system are fixed.
Refer to section 3.4.7.
6
Control Module (BMS) and Battery Module are
installed well.
Refer to section
3.4.7.
7
Connect
D+
and
D-
between BMS to the
inverter/PCS or confluence cabinet.
Refer to section
3.5.3.1.
8
Connect the grounding cable.
Refer to section
3.5.1.
9
Double check all the
power cables
,
communication cables, grounding cable
are
installed well.
Refer to section
3.5.1,3.5.2 and 3.5.3.
10
Switch the external power or inverter/PCS on,
ensure all the power equipment can work
normally.
Refer to section 4.1.
11
The first installation should do full charging
progress automatically.
If the status LED of BMS turns to blue, it means
this battery string is in operation.
