17
Multi-strings starting sequence: please start up the last string (from communication
structure, the last slave string, see the table blow) of battery system first, one by one to the
first string which shall be started up lastly. Details as below table.
Master string
*
Last Start up
Slave string 1 5th Start up
Slave string 2 4th Start up (if has)
Slave string 3 3rd Start up (if has)
Slave string 4 2nd Start up (if has)
Slave string 5 1st Start up (if has)
* BMS of the rack with Link Port 0 EMPTY is defined as the Master string, which communicates with the
inverter or upper controller. In one system, there’s ONLY
ONE Master string, the rest are defined as the
slave strings.
Black start function: When the system is turned on, and relay is OPEN, press the Start Button
more than 10 secs. Then relay will be CLOSE for about10mins without communication
(depending on conditions).
Multi-strings Black Start: Black start operation is ONLY needed to be performed on Mater
string. And it will close circuit for one of the strings within the system for 10mins. The slave
string black start function is ONLY controlled by master string.
Wi-Fi
Manufacturer: Pylon Technologies Co., Ltd.
Address: Plant 8, No.505 Kunkai Road, JinXi Town, 215324 Kunshan City, Jiangsu Province,
PEOPLE'S REPUBLIC OF CHINA
Importer: XXXX （Located in installed country）
Address: XXXX （Located in installed country）
Basic Information of Wi-Fi
Wireless Max. Output Power
15dBm
Operating frequency
2412-2472MHz
Gain of antenna
Max 3dBi
Modulation system
DBPSK/DQPSK/CCK(DSSS)
BPSK/QPSK/16QAM/64QAM(OFDM)
Modulating Repetition
1Mbps/2Mbps/5.5Mbps/11Mbps (DSSS)
6Mbps/9 Mbps/12 Mbps/18 Mbps/24 Mbps/36 Mbps/48
Mbps/54 Mbps (OFDM)
MCS0~MCS7 (802.1 1n 20MHz)
Channel spacing
5MHZ
Type of antenna
2.4G IPEX-SMA Antenna
