PYROLOGIC 2000 SYSTEM - Remote Controlled Unit; Remote Controlled Unit-16

Getting started
5
WARNING: Do not operate TU with rechargeable batteries.
Terminal Unit Master Key
Remote Controlled Unit
Front
:
c Squib Contacts
d Foldable Antenna
e Green LED
f Red LED
g Test Key
h Power Key
Back
:
z Battery Bay with transparent cover
z Battery (9 Volt alkaline battery - Not Included)
z Transparent foldable leg
Remote Controlled Unit- 16
The Remote Controlled Unit - 16 includes the following elements:
Front Panel with Green LED and Red LED and Test and Power Keys
16 Squib Contacts
Foldable Antenna
Battery Bay with transparent cover
Battery (9 Volt alkaline battery - Not Included)
Transparent foldable leg
BASE UNIT, EXTENSION UNIT and EXTERNAL PTT are detailed in a separate
manual.
