Operating the System
21
Firing
Firing Preparations
1. Connect squib/electric match-head to the RCU.
2. Press the Test button on the RCU.
3. If green LED lights, circuit is OK. If Red LED lights, circuit is not
functional – change the squib.
4. Connect the squib to the firework/shell.
Setting RCUs Sleep State and Alarm
This step is optional.
Sleep
If there is time left until the event, you can put the RCUs into sleep state.
1. At the TU main settings menu, select SET UNITS menu.
2. In the SET UNITS menu, select SLEEP.
The TU will send the RCUs a SLEEP command. The RCUs will go into sleep state,
with the green and red LEDs blinking together every 5 seconds.
Wakeup
If you want to wake up the sleeping RCUs, and the TU power is not
turned off:
1. At the TU main settings menu, select SET UNITS menu.
2. In the SET UNITS menu, select WAKE-UP.
The TU will send the RCUs a WAKEUP command. The RCU's will go into Standby
state, with the red LED blinking.
If the TU power has been turned off, you will wake up the sleeping RCUs by turning
the TU power on. The TU will send the RCUs a WAKEUP command. The RCUs
will go into Standby state, with the red LED blinking.
Alarm
You can set an ALARM time.
1. At the TU main settings menu, select SET UNITS menu.
2. In the SET UNITS menu, select SET ALARM TIME. The following
screen will be displayed:
