Terminal Unit Menus
11
ADD UNITS
ADD UNITS will give you the possibility to teach the RCUs their address (Group #,
RCU #). It will also give you the opportunity to check the system for interference
after placing the RCUs at the display location.
On the main settings menu, select ADD UNITS to display the following screen:
1.RCU x 1
2.RCU x 16
3.TEST 1 SEC.
RCU X 1
On the ADD UNITS screen, select RCU X 1 to display the following screen:
GROUP 1 RCU 01
Menu Options:
GROUP: 1 to 8
RCU: 01 to 16
To teach the RCU its address:
On the RCU, press Test and Pwr keys together. Green LED will go on first and then
red LED and both LEDs will blink together.
On the TU, press Enter. RCU LEDs will light together for 1 second and then go off.
RCU address has been assigned. Insert address into the battery bay visible through
transparent battery cover.
RCU X 16
On the ADD UNITS screen, select RCU X 16 to display the following screen:
GROUP 1
METHOD:
ALL TOGETHER
Menu Options:
GROUP: 1 to 8
METHOD: ALL TOGETHER or ONE BY ONE
If you choose ALL TOGETHER, all squibs that are connected to the RCUX16 will
fire simultaneously.
