Terminal Unit Menus
8
Terminal Unit Menus
Note: If the TU is turned off, start-up the system as described
in "System Start-Up" on page 16.
Main Settings Menu
1.EVENTS CONTROL
2.ADD UNITS
3.SET UNITS
4.TU SETTINGS
From this screen, you can access all the menus and functions of the system.
EVENTS CONTROL
On the main settings menu, select EVENTS CONTROL to display the EVENTS
CONTROL screen:
1.SELECT EVENT
2.PROGRAM EVENT
3.CLEAR EVENT
4.CHOOSE EVENT
From this screen you can access all the events related menus and functions.
SELECT EVENT
On the EVENTS CONTROL screen, select SELECT EVENT to display the SELECT
EVENT screen:
SELECT EVENT
Choose event
from 1 to 8
1
In this screen you can choose 8 different events for each of the Manual, Semi-
automatic and Automatic modes. You can select between 8 events programmable on
the Memory Key by pressing a Numeric Programming Key.
PROGRAM EVENT
On the EVENTS CONTROL screen, select PROGRAM EVENT. If you logged into the
system with Low Level password, you will be prompted to enter the High Level
password.
