EURO 46 Installation Manual
Page: 46
8.9 Problem Solving
One of the most frequent problems in not being able to assign the detectors to the Radio Expander is
that the jumper on the detector PCB has not been put in place on the ‘EU’ pins. This makes sure the
transmitter transmits at the correct 868MHz frequency which the input expander uses.
Make sure that the ‘serial’ jumper on the radio expander is in the ‘MF’ position.
If there is “33” displayed on the screen and can’t be cleared, it is because the expander has been
selected for “A0” not “E0”. You will need to power down the expander and address it again.
8.10 Technical Specification
THE RADIO EXPANDER
Radio: Inovonics Wireless EchoStream using Pan-European 868MHz
Housing Material: ABS
Closure: Latching with optional screws for high security installs
Dimensions: 162.0 x 91.4 x 27.9 mm
Weight: 204 grammes
Power Requirements: 12-24V AC or DC
Battery Capacity: 1800mAH at 3.7V
Back-up Battery Life: 24 hours typical
Operating Environment: 0° - 60° C up to 90% relative humidity (non-condensing)
Batt. Charger Operating
Environment:
0° - 40° C
Conformity: Meets or exceeds EN50131-5-3 at grade 2
