4. SYSTEM OVERVIEW & TECHNICAL SPECIFICATIONS
This manual supports the following panels: Matrix 424, Matrix 832 and Matrix 832+.
4.1 System Overview
4.1.1 Zones
Zones on Main Board Matrix 424
Matrix 832/832+
4 fully programmable zones
8 fully programmable zones
Zone Expander (On Board) 8 fully programmable zones on local plug in expander
Zone Expander MX-RIX Matrix 424
Matrix 832/832+
8 fully programmable zones on remote expander
8 fully programmable zones on remote expander
Zone Expander
MX-RIX8DW
Matrix 424
Matrix 832/832+
8 fully programmable zones on remote expander
8 fully programmable zones on remote expander
Maximum Zones
Capacity
Matrix 424
Matrix 832/832+
28 zones using 3 x zone expanders
32 zones using 3 x zone expanders (64 with zone doubling)
Zone Configurations Normally Closed
DEOL – 2 end of line resistors per zone
Zone Types Entry/Exit, Access, Immediate, Omit (Bypass), Fire, PA, 24Hr,
Key Box, Shunt Keypad, Tamper, Latched Key, Momentary Key,
Unused, Medical, Arm
Zone Attributes Chime, Test, Mask, Double knock, Normally open
4.1.2 Programmable Outputs (PGM)
PGM Outputs On-Board PGM 1 – NO/NC
PGM 2 – NO/NC (832+), Active High / Active Low (424/832)
PGM 3 – Active High / Active Low
PGM 4 – Active High / Active Low
Output Expander MX-ROX 8 open collector/relay expander – installable remotely on keypad bus
Maximum PGM Outputs Capacity 12 outputs using output expander
PGM
Options
Not Used
PIR Remote LED enable (E-)
PIR Latch Memory (C+)
RKP Controlled
Follow Arm/Disarm
Follow Zone
Follow Tel Line Fail
Follow Kiss Off
Shock/Fire Sensor Reset
Follow Strobe
Follow Fire Alarm
Follow PA Alarm
Follow Confirmed Alarm
Twin Alert
Follow Entry Exit
Follow Digi Com - Fire Alarm
Follow Digi Com - PA Alarm
Follow Digi Com - Intruder Alarm
Follow Digi Com - Open/Close
Follow Digi Com - Spare Alarm
Follow Digi Com - Medical Alarm
Follow Digi Com - Confirm Alarm
Follow Digi Com - Omits (Bypass)
Follow Hidden Display
Follow Mains Fail
Follow Battery Low
Follow Battery Faults
Follow Duress
Follow Disarmed
Follow System Faults
Momentary Burglary
Follow Momentary 24H
Follow Momentary FIRE
Follow Momentary MEDICAL
Follow Momentary PA
Follow Momentary TAMPER
Follow Momentary DURESS
Follow Momentary COMFAIL
Follow Momentary RKPFAIL
