Matrix 424, 832, 832+ Installation Manual
Page 48 RINS918-6
Battery Capacity Operational
Plastic Enclosure 2.8 to 7Ah Plastic Case 0 to +40ºC (32 to 104ºF)
Metal Enclosure (832+) 2.8 to 17Ah* Metal Case (832+) -10 to +55ºC (14 to 131ºF)#
BAT Terminal Protection Short & reverse Storage -20 to +60ºC (-4 to 140ºF)
Low Battery Detect Level 10.7V ± 0.2V Maximum Humidity
Battery Cut-off Level 10.4V ± 0.2V
(with MX-BATT) Plastic Case N/A
Metal Case (832+) 93% Rh
* NOTE - Italy: To conform with CEI79, the maximum battery size is limited to 12Ah.
# NOTE - Italy: To conform with CEI79 the operational temperature must be
0 to +40ºC (32 to 104ºF).
4.3.2 Keypads, Proximity Reader & Additional Expanders
ICON KEYPAD LCD KEYPAD
Supply Voltage 13.8V typical (9-16V range) Supply Voltage 13.8V typical (9-16V range)
Supply Current
Supply Current
Min. brightness setting 40mA @ 13.8V Min. brightness setting 20mA @ 13.8V
Max. brightness setting 60mA @ 13.8V Max. brightness setting 80mA @ 13.8V
Operating temperature 0 to +50ºC (32 to 122ºF) Operating temperature 0 to +50ºC (32 to 122ºF)
Dimension 75 x 127 x 29 mm Dimension 139 x 127 x 29 mm
WIRELESS ZONE EXPANDER (MX-RIX8DW)
USER KEY FOB (KF4DW)
Supply Voltage 13.8V typical (9-16V range) Battery 3V 360mAhr
Quiescent Current 100mA Battery Life Up to 1 year
Transmitting Current 135mA Buttons 4
All LEDs on current 120mA Progammable Actions 6
Transmission Frequency
868MHz, FM Transceiver
Narrow Band
Transmission Frequency
868MHz, FM Transceiver
Narrow Band
Transmission Method Fully Encrypted Rolling Code Transmission Method Fully Encrypted Rolling Code
Transmission Range 300m Free Space Colour Black
Programming LEDs 11 Casing 2mm Polycarbonate
Supported Zones 8
Supported Keyfobs 32
PROXIMITY READER (MX-PROX)
VOICE MODULE (MX-VOICE)
Supply Voltage 13.8V typical (9-16V range) Supply Voltage 13.8V typical (9-16V range)
Supply Current Max. 90mA @ 13.8V Supply Current Max. 25mA @ 13.8V
Operating temperature -10 to +50ºC (14 to 122ºF) Number of messages 8
Dimension 85 x 85 x 21 mm Message length up to 7 sec.
LOCAL PLUG-ON ZONE EXPANDER (MX-IX16)
REMOTE MX-RIX WITH ZONE ANALYSER
Supply Voltage 13.8V typical (9-16V range) Supply Voltage 12V typical (9-16V range)
Supply Current 15mA ± 5% @ 13.8V Supply Current 25mA ± 5% @ 13.8V
Zone Loop Current 0.54mA – Max. Zone Loop Current 0.54mA – Max.
Zone Activation Resistance See main control panel data Zone Activation Resistance See main control panel data
TRANSISTOR OUTPUT EXPANDER (MX-ROX8T)
RELAY OUTPUT EXPANDER (MX-ROX8R)
Supply Voltage 13.8V typical (9-16V range) Supply Voltage 13.8V typical (9-16V range)
Supply Current 45mA ± 5% @ 13.8V Supply Current 225mA ± 5% @ 13.8V
Outputs 8 Open collectors Outputs 8 NO/NC contacts
Max. Switching Voltage 12Vdc Max. Switching Voltage 30V
Max. Switching Current 500mA Max. Switching Current 3A
