12
FLOOR ANCHORAGE LAYOUT REQUIREMENTS
o
Safety eye glasses MUST be worn whenever installing or servicing this system.
o
Before installation, inspect the underside of vehicle oor, note utilities, frames, cross-members, fuel tanks and other
possible obstructions—any questions contact the vehicle OEM.
o
Vehicle anchor points may require reinforcement. The installer or manufacturer is responsible for ensuring
anchorages are installed into suitable oor structures. Floor strength MUST meet specic regulations, standards and
applicable performance requirements from local transportation authorities.
o
Do NOT install anchorages or any system components into faulty materials such as corroded metal, wood, plastic or
berglass panels.
o
The oor and shoulder belt anchorages MUST be installed onto a at and durable surface.
o
Only use Hardware with a minimum Grade 8, which meets ASTM F835 ,SAE J429 or ASTM 574 specications
(depending on head style and drive), and coated for adequate protection against corrosion per ISO 7253 or ASTM B117
or per customer requirements.
o
Modications to Backing Plate MUST only be made where necessary as a smaller plate size reduces the oor load
distribution. Always leave a minimum of .6” (15mm) adjacent the bolt hole in the plate.
o
Electrical Retractors are designed and tested to ONLY be used in the front positions together with Q’Straint® 4-Point
Securement Systems.
o
Electrical Retractors MUST be mounted in a horizontal plane so that the webbing does not jam or at a 30 degree angle
using Q’Straint Bracket (part # Q8-6510).
o
The following items should be inspected and serviced by an experienced and trained technician during the scheduled
maintenance:
o
Clean all debris from oor anchorages.
o
Verify that oor anchorages are not damaged or corroded.
o
Verify that all mounting bolts are tight.
o
Inspect entire system to make sure everything is working properly and replace anything that is needed.
o
Rigid components inside the clear zones (2a & 2b) should be covered with padding that conforms to the impact
requirements of FMVSS 201 or ECE R21
o
Additional vehicle interior padding should have a burning rate that does not exceed 100mm/min when tested in
accordance with ISO 3795
