Icon name Icon Description
Controller fan status • Icon lit: Fan module in both controllers operating
correctly
• Icon flashing: Fan module in both controllers operating
incorrectly or not installed
If both controllers installed:
• Icon flashing: Fan module in controller A operating
incorrectly or not installed
If only controller A installed:
• Icon lit: Fan module in controller A operating correctly
• Icon flashing: Fan module in controller A operating
incorrectly or not installed
If both controllers installed:
• Icon flashing: Fan module in controller B operating
incorrectly or not installed
If only controller B installed:
• Icon lit: Fan module in controller B operating correctly
• Flashing: Fan module in controller B operating
incorrectly or not installed
ES1686dc User Guide
