QNAP QHora-321 User Manual

LED Status Description
2.5 Gigabit
Ethernet (1
Gbps or 100
Mbps speed)
Orange The network connection is operating at 1 Gbps or 100 Mbps.
Flashes orange Data is being transmitted.
O There is no network connection.
2.5 Gigabit
Ethernet WAN
Orange A WAN connection has been established.
2.5 Gigabit
Ethernet LAN
Green A LAN connection has been established.
Reset Button
QNAP routers can be reset to factory defaults using the reset button located on the rear side of the device.
For details on the component placement, see the rear side of the device.
Operation User Action Result
Reset Press and hold the button for 10
seconds
The router resets and all default settings are restored.
This will clear any statically assigned IP address
information, WAN and LAN congurations, and security
settings.
The router is unbound from the QNAP ID.
QHora-321 User Guide
Basic Operations 14

QNAP QHora-321 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Concurrent connections	50000
Ethernet LAN data rates	100, 1000, 2500 Mbit/s
Ethernet interface type	2.5 Gigabit Ethernet
Flash memory	4 MB
Certification	CE / FCC / VCCI / BSMI / RCM / CCC / UKCA
Storage media	Flash
Internal memory	4096 MB
Processor model	CN9130
Processor frequency	2.2 MHz
Internal memory type	DDR4
Processor manufacturer	Marvell
Internal storage capacity	4 GB
Web-based management	-
Output voltage	12 V
Power source type	DC
Power consumption (typical)	36 W
Package weight	1350 g
Cables included	AC, LAN (RJ-45)
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Ethernet LAN (RJ-45) ports	6
Product color	White
VPN support	L2TP, WireGuard, OpenVPN, QBelt
Firewall security	TCP, UDP, ICMP, TCP+UDP

Weight and Dimensions

Depth	145.7 mm
Width	166.4 mm
Height	29.85 mm
Weight	810 g
