Setting User Action
Permission Select one of the following:
• Allow
• Deny
5. Click Save.
QSS adds the IP address–based ACL rule.
Adding a MAC address–based ACL rule
1. Log in to QSS.
2. Go to Conguration > ACL > By MAC Address .
3. Click Add.
The Add ACL - MAC Address window opens.
4. Congure the ACL settings.
Setting User Action
ACL No. Specify a number between 1 and 255.
Source
MAC address Specify the source MAC address.
Destination
MAC address Specify the destination MAC address.
Port Select specic ports to apply the ACL rule, or select All to apply the rule
to all ports.
Permission Select one of the following:
• Allow
• Deny
5. Click Save.
QSS adds the MAC address–based ACL rule.
Conguring QoS settings
Quality of service (QoS) enables the switch to examine incoming packets and classify them into groups to
prioritize certain trac over others. You can classify these packets based on the type of trac, source, or
destination address. QSS allows you to congure and enable trac policies on the switch ports using two
QoS classication techniques, Dierentiated Services Code Point (DSCP) and class of service (CoS).
1. Log in to QSS.
2. Go to Conguration > QoS > QoS .
3. Identify a port or LAG.
4.
Under DSCP, click .
DSCP is enabled on the switch port.
