21
3.2. REXP-1220URP and REXP-1620U-RP Rear view
1 COM Port (Reserved)
2-4
Three mini SAS ports
5 Power Switch
6 Enclosure ID
7 Power Connection
LED Color State Description
Link Status
Green Green Port linked
Flash green Data is being transmitted
Off No link activity
Link Fault Amber Amber Port linked but without all four
lanes
