QNAP TS-228A User Manual

c. Attach the tool-less screw to the bottom of the NAS.
8. Connect all cables and external attachments.
9. Connect the power cord to the electrical outlet.
10. Power on the NAS.
QTS Installation
Installing QTS Using Qfinder Pro
Warning
Installing QTS deletes all data on the drives. Back up your data before proceeding.
1. Power on the NAS.
2. Connect the NAS to your local area network.
3. Run Qfinder Pro on a computer that is connected to the same local area network.
Note
To download Qfinder Pro, go to https://www.qnap.com/utilities.
4. Locate the NAS in the list and then double-click the name or IP address.
The Smart Installation Guide opens in the default web browser.
5. Perform any of the following actions.
• To check for the latest available version, click Start.
The wizard downloads the latest available version, and then the NAS restarts after the download
is complete. If a newer version is not available, the wizard automatically displays the Smart
Installation Guide.
• To install the out-of-the-box version, click Skip.
6. Click Start Smart Installation Guide.
TS-x28A User Guide
Installation and Configuration 10

QNAP TS-228A Specifications

General

Type	NAS
Noise level	17 dB
Device class	Home & Home Office
Backup button	Yes
Backup features	Cloud, iSCSI LUN
Browser supported	Apple Safari 7, Google Chrome, Microsoft Internet Explorer 10, Mozilla Firefox
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SNMP, SSH
Storage drive size	- \
Storage drive capacity	0 GB
Supported file systems	FAT32, HFS+, NTFS, ext3, ext4
Storage drive interface	-
Storage drives installed	No
Storage drive sizes supported	3.5 \
Supported storage drive types	HDD
Total installed storage capacity	0 TB
Number of storage drives installed	0
Number of storage drives supported	2
Supported storage drive interfaces	Serial ATA, Serial ATA II, Serial ATA III
Operating system version	4.3.4
Operating system installed	QNAP Turbo System
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply location	External
Power consumption (typical)	12.21 W
Power consumption (HDD standby)	5.14 W
Power supply unit (PSU) capacity	60 W
Processor cores	4
Processor model	RTD1295
Processor family	Realtek
Processor frequency	1.4 GHz
Processor architecture	ARM Cortex-A53
Cables included	AC, LAN (RJ-45)
Flash memory	4000 MB
Internal memory	1 GB
Internal memory type	DDR4
Ethernet LAN data rates	1000 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Chassis type	Mini Tower
Cooling type	Active
Fan diameter	40 mm
Product color	White
LED indicators	HDD, Network, Status, System
Number of fans	1 fan(s)
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	125 mm
Width	90 mm
Height	187.7 mm
Weight	700 g
Package weight	1880 g
