QNAP TS-410 User Manual

6.2 TS-879U-RP, TS-1279U-RP
1. T
urn off the NAS. Disconnect the power adaptor, network cable(s), and any other
connectors or cables from the NAS.
2. Before installing the network expansion card, put on an antistatic wrist strap to prevent
electrostatic discharge. The crocodile clip should be connected to the ground.
3. Loosen the two screws on the rear of the NAS.
4. Hold t
he notch at the edge of the top cover. Remove the top cover in both hands.
35

QNAP TS-410 Specifications

General

CPU	Marvell 6281
CPU Frequency	800 MHz
Flash Memory	16 MB
Drive Bays	4
LAN Ports	1 x Gigabit RJ-45 Ethernet port
Dimensions	177 x 180 x 235 mm
Weight	3.6 kg
Hot Swappable	Yes
RAID Support	RAID 0, 1, 5, 6, JBOD
USB Ports	3 x USB 2.0
eSATA Ports	2
Maximum Internal Raw Capacity	16 TB (4 x 4 TB hard drives)
