QNAP TS-410 User Manual

Chapter 9. Use the LCD Panel
This feature is only provided by the NAS models with LCD panels. Please visit
http://www.qnap.com
for details.
The NAS provides a handy LCD panel for users to perform disk configuration and view the
system information.
When the NAS has started up, the server name and IP address will be shown.
N A S 5 F 4 D E 3
1 6 9 . 2 5 4 . 1 0 0 . 1 0 0
For the first time installation, the LCD panel shows the number of hard drives detected and
the IP address. Configure the hard drives.
Number of hard
drives detected
Default disk
configuration
Available disk configuration options*
1 Single Single
2 RAID 1 Single -> JBOD ->RAID 0 -> RAID 1
3 RAID 5 Single -> JBOD -> RAID 0 -> RAID 5
4 or above RAID 5
Single ->JBOD -> RAID 0 -> RAID 5
-> RAID 6
*Press the “Select” button to choose the option, and press the “Enter” button to confirm.
43

QNAP TS-410 Specifications

General

CPU	Marvell 6281
CPU Frequency	800 MHz
Flash Memory	16 MB
Drive Bays	4
LAN Ports	1 x Gigabit RJ-45 Ethernet port
Dimensions	177 x 180 x 235 mm
Weight	3.6 kg
Hot Swappable	Yes
RAID Support	RAID 0, 1, 5, 6, JBOD
USB Ports	3 x USB 2.0
eSATA Ports	2
Maximum Internal Raw Capacity	16 TB (4 x 4 TB hard drives)
