QNAP TS-410 User Manual

Chapter 5. Upgrade Memory on QNAP Turbo NAS (RAM Module
Installation)
Warning:
 The following instructions should only be performed by an authorized and trained
technician.
 Strictly adhere to the instructions to install a RAM module on the NAS. Failure to do
so could result in injury to human body or death.
QNAP provides 1GB DDR3 RAM module (optional purchase) for users to upgrade the
memory of Turbo NAS. Follow the steps below to install an extra memory module on the
NAS to upgrade the memory.
5.1 TS-x59 Pro II series (4/5/6-bay)
F
ollow the steps below to install a RAM module on the NAS.
1. Turn off the NAS. Disconnect the power adaptor, network cable(s), and any other
connectors or cables from the NAS.
2. Before installing the memory module, put on an antistatic wrist strap to prevent
electrostatic discharge. The crocodile clip should be connected to the ground.
3. Loosen the three screws on the rear of the NAS.
24

QNAP TS-410 Specifications

General

CPU	Marvell 6281
CPU Frequency	800 MHz
Flash Memory	16 MB
Drive Bays	4
LAN Ports	1 x Gigabit RJ-45 Ethernet port
Dimensions	177 x 180 x 235 mm
Weight	3.6 kg
Hot Swappable	Yes
RAID Support	RAID 0, 1, 5, 6, JBOD
USB Ports	3 x USB 2.0
eSATA Ports	2
Maximum Internal Raw Capacity	16 TB (4 x 4 TB hard drives)
