QNAP TS-453E User Manual

10. Select the paired folders.
Important
• All subfolders and les in the selected folder are selected.
• You can only sync up to 16 paired folders per job.
a.
Under the source, click
.
A dialog box opens.
b. Select a folder.
c. Click OK.
The dialog box closes.
d.
Under the destination, click .
A dialog box opens.
e. Select a folder.
f. Click OK.
g. Optional: Add more paired folders if necessary.
11. Click Next.
The Schedule screen appears.
12. Select Sync now.
13. Click Next.
The Rules screen appears.
14. Optional: Congure job rules.
15. Click Next.
The Summary screen appears.
16. Review the job summary.
17. Click Create.
The source NAS runs the created one-way sync job.
Note
It may take several minutes to migrate shared folders from the source NAS to the destination
NAS.
Importing Local Users or Group Settings to the Destination NAS
1. Power on the source NAS.
2. Back up the users or group settings from the source NAS.
a. Log on to QTS.
b. Go to Control Panel > Privilege > Users .
c. Click Create, and then click Import/Export Users.
The Import/Export Users window appears.
TS-x53E User Guide
NAS Migration 42

QNAP TS-453E Specifications

General

GPU	Intel UHD Graphics
Flash Memory	4 GB (Dual boot OS protection)
Drive Bays	4 x 3.5-inch SATA 6Gb/s, 3Gb/s
Hot-swappable	Yes
M.2 SSD Slot	2 x M.2 2280 PCIe Gen3 x1
SSD Cache Acceleration Support	Yes
Network Interface	2 x 2.5GbE RJ45
Form Factor	Tower
LED Indicators	Status, LAN, USB, HDD 1-4
Kensington Security Slot	Yes
Operating System	QTS 5.0
Processor	Intel Celeron J6412
CPU Architecture	64-bit x86
Memory	8 GB DDR4 (4 GB x 2)
Memory Slot	2 x SO-DIMM
Drive Compatibility	3.5-inch SATA hard disk drives, 2.5-inch SATA solid state drives
Maximum Internal Raw Capacity	64 TB (16 TB drive x 4)
Buttons	Power, Reset
Power Supply Unit	100-240V
Fan	1 x 120mm
Operating Temperature	0°C to 40°C (32°F to 104°F)
Operating Humidity	5% to 95% RH
