c. Lift the cover until it is completely detached from the chassis.
7. Remove expansion cards.
a. Remove the screw that secures the expansion card to the chassis.
Note
• The pan head M3x5 screw requires a Phillips #2 screwdriver.
• A torque of 5 kgf.cm (4.34 lbf.in) ± 0.5 kgf.cm (0.43 lbf.in) is recommended for
electric screwdrivers.
b. Hold the card by the edges.
| NAS Repair Manual
Category D NAS Models 99
