5. Remove all drive trays.
Important
Remember the number of each drive. Each drive will need to be returned to their original
bay.
6. Remove the case cover.
a. Remove the screws on the rear panel.
Note
• The at head M3x4 screws require a Phillips #2 screwdriver.
• A torque of 5 kgf.cm (4.34 lbf.in) ± 0.5 kgf.cm (0.43 lbf.in) is recommended for
electric screwdrivers.
b. Slide the cover back.
| NAS Repair Manual
Category D NAS Models 98
