c. Remove the screws that secure the front panel to the chassis.
Note
• The pan head M3x5 screws require a Phillips #2 screwdriver.
• A torque of 5 kgf.cm (4.34 lbf.in) ± 0.5 kgf.cm (0.43 lbf.in) is recommended for
electric screwdrivers.
• On other models, there may also be screws that secure the front panel to the
bottom of the chassis.
d. Release the latches that secure the front panel to the chassis.
| NAS Repair Manual
Category D NAS Models 109
