b. Attach the screws that secure the tray to the front of the chassis.
Note
• The at head M3x4 screws require a Phillips #2 screwdriver.
• A torque of 5 kgf.cm (4.34 lbf.in) ± 0.5 kgf.cm (0.43 lbf.in) is recommended for
electric screwdrivers.
c. Position the chassis on its left side.
d. Attach the screws that secure the tray to the bottom of the chassis.
| NAS Repair Manual
Category D NAS Models 120
