Note
Larger expansion cards may require you to attach the PCIe power connector before inserting
the card into the slot.
8. Attach the case cover.
a. Place the cover on the device.
b. Slide the cover forward.
c. Tighten the screws.
9. Connect all cables and external attachments.
10. Connect the power cord to the electrical outlet.
TS-h1290FX User Guide
Installation and Conguration 23
