Moving fan blades: Keep your hands and other body parts away from moving fan
blades.
•
Other moving components: Keep your hands and other body parts away from other
moving components.
1. Power o the device.
2. Remove the case cover.
For details, see Removing the Case Cover.
3. Remove an existing module.
a. Push the retention clips outward simultaneously to release the module.
Warning
Attempting to remove a module that is not completely released may damage the module and
the motherboard.
b. Hold the module by the edges.
c. Carefully slide the module out of the slot.
4. Install a new module.
a. Align the notch with the ridge in the slot.
b. Insert the module into the slot.
TS-h1886XU-RP User Guide
Installation and Conguration 24
