QNAP TS-h1886XU-RP-R2 User Manual

Expansion Unit Model Description Required Accessories
TL-D400S • Uses a SATA 6 Gbps (SFF-8088)
interface
• Supports SATA HDD/SSD
• 1 x SFF-8088 connector cable
• QXP-400eS-A1164 host bus
adapter
TL-D800S • 2 x SFF-8088 connector cables
• QXP-800eS-A1164 host bus
adapter
TL-D1600S • 4 x SFF-8088 to SFF-8644
connector cables
• QXP-1600eS-A1164 host bus
adapter
TL-R400S • 1 x SFF-8088 connector cable
• QXP-400eS-A1164 host bus
adapter
• RAIL-B02
TL-R1200S-RP • 3 x SFF-8088 to SFF-8644
connector cables
• QXP-1600eS-A1164 host bus
adapter
• RAIL-B02
TR-002 • Uses a USB 3.2 Gen 2 Type-C
interface
• Supports SATA HDD/SDD
• USB 3.2 Gen 2 Type-A to Type-
C cable
TR-004 • Uses a USB 3.2 Gen 1 Type-C
interface
• Supports SATA HDD/SDD
TR-004U • USB 3.2 Gen 1 Type-A to Type-
C cable
• RAIL-B02
TL-D800C • Uses a USB 3.2 Gen 2 Type-C
interface
• Supports SATA HDD/SDD
• USB 3.2 Gen 2 Type-A to Type-
C cable
TL-R1200C-RP • USB 3.2 Gen 2 Type-A to Type-
C cable
• RAIL-B02
Connecting SAS Expansion Units
To connect the device to SAS expansion units, a storage expansion card must be installed in the device.
For required accessories details, see Expansion Unit Installation.
1. Install a storage expansion card on the PCIe slot.
For details, see Replacing Expansion Cards.
2. Connect the expansion units to the device using the following topology.
TS-h1886XU-RP User Guide
Installation and Conguration 31
