The panel displays the name and capacity of the next volume.
6. Optional: Repeat step 5 as necessary.
Viewing System Information
The LCD panel can display the CPU temperature, system temperature, and system fan speed.
1. Press Enter or Select.
The panel displays the NAS name and QuTS hero version.
2. Press and hold Enter for two seconds.
The panel displays Main Menu 1. TCP/IP.
3. Press Enter repeatedly until the panel displays Main Menu 4. System.
4. Press and hold Enter.
The panel displays the CPU and system temperature.
5. Press and hold Select.
The panel displays the system fan speed.
Powering Off the NAS
1. Press Enter or Select.
The panel displays the NAS name and QuTS hero version.
2. Press and hold Enter for two seconds.
The panel displays Main Menu 1. TCP/IP.
3. Press Enter repeatedly until the panel displays Main Menu 5. Shut down.
4. Press and hold Enter.
The NAS powers off.
Restarting the NAS
1. Press Enter or Select.
The panel displays the NAS name and QuTS hero version.
2. Press and hold Enter for two seconds.
The panel displays Main Menu 1. TCP/IP.
3. Press Enter repeatedly until the panel displays Main Menu 6. Reboot.
4. Press and hold Enter.
The NAS restarts.
LCD Error Messages
System Message Description
Sys. Fan Failed System fan has failed.
Sys. Overheat System has overheated.
HDD Overheat Drive has overheated.
CPU Overheat CPU has overheated.
TS-hx86 User Guide
Basic Operations 51
