Power Specifications
1
– 8-Channel Models
CX-Q 4K8 / CX-QN 4K8 CX-Q 8K8 / CX-QN 8K8
Configuration Loads
Max Power
2
Continuous
Power
Max Power
2
Continuous
Power
4 or 8 Independent Channels
A, B, C, D, E, F, G, H
100 V
1000 300 1250 600
70 V
1000 300 1250 600
16 Ω
500 150 625 300
8 Ω
1000 300 1250 600
4 Ω
1000 300 1500 600
2 Ω
800 300 1000 300
Parallel Channels (x2)
AB or CD or EF or GH
Doubles Current
Best for high power 70V &
100V
100 V
1500 600 2000 1100
70 V
1500 600 2000 1200
8 Ω
1000 600 1250 1100
4 Ω
1250 600 2400 1200
2 Ω
1500 600 2500 600
Parallel Channels (x3)
ABC, DEF
Triples Current
8 Ω
1000 900 1250 1100
4 Ω
1500 900 2000 1800
2 Ω
1500 900 2500 1800
BTL/Bridged Channels (x2)
A+B or C+D or E+F or G+H
Doubles Voltage
Do NOT use for 70V or 100V
200 V
1500 600 2000 1200
140 V
1500 600 2000 1200
8 Ω
1500 600 3000 1200
4 Ω
1400 400 1700 600
2 Ω
N/R
3
N/R
3
BTL/Bridged & Paralleled
Channels (x4)
AB+CD, EF+GH
Doubles Current and Voltage
8 Ω
2500 1200 4000 2400
4 Ω
3000 1200 5000 2400
2 Ω
N/R
3
N/R
3
Parallel Channels (x4)
ABCD, EFGH
Quadruples Current
8 Ω
1000 1000 1200 1200
4 Ω
2000 1200 2400 2200
2 Ω
2500 1200 4000 2400
1 Ω
3000 1200 4000 2400
1 Specifications are subject to change without notice.
2 Max Power
» Max Power data is based on the most potential any single amplifier channel can deliver. This data is most useful for asymmetrical loading
of amplifier channel and maximizing power utilization of the amplifier. When utilizing FlexAmp™ power requirements, be sure to take into
consideration the power capabilities of the channel AND the capabilities of the Power Supply.
» Continuous Power indicates amplifier output capabilities with all channels driven with the same load without exceeding the capabilities of the power
supply.
» Power Spec is based on 1 kHz, 20 msec
3 N/R = Not Recommended
