QSC CX-Q Series User Manual

17
TD-001586-01-B
Specifications
1
Power Specifications – 4-Channel Models
CX-Q 2K4 / CX-Q 2K4 CX-Q 4K4 / CX-Q 4K4 CX-Q 8K4 / CX-Q 8K4
Max Power
2
Continuous
Power
Max Power
2
Continuous
Power
Max Power
2
Continuous
Power
Configuration Loads
Independent Channels (SE)
A, B, C, D
100 V
700 350 1000 550 1250 1150
70 V
700 400 1000 625 1250 1150
16 
350 200 500 313 625 625
8 
700 400 1000 625 1250 1250
4 
800 400 1500 625 2400 1250
2 
600 300 800 400 2750 1250
2 channels combined in
Parallel
AB or CD
Doubles current
Best for high power 70V &
100 V
100 V
1400 700 2000 1150 2400 2000
70 V
1400 750 2000 1150 2400 2000
8 
800 400 1000 625 1250 1250
4 
1250 750 2000 1250 2400 2250
2 
1500 650 2500 1250 4000 2100
3 channels combined in
Parallel ABC
Triples current
8 
800 400 1000 1000 1250 1250
4 
1250 800 2000 2000 2400 2400
2 
1500 1100 3000 2500 4500 3000
2 channels combined in BTL
Bridged A+B or C+D
Doubles voltage
Do NOT use for 70 V or100 V
200 V
1500 700 2000 1250 2400 2000
140 V
1500 700 2000 1250 2400 2000
8 
1500 700 3000 1250 4000 2250
4 
1400 600 1700 1150 5000 2500
2 
N/R
3
N/R
3
N/R
3
N/R
3
3000 2000
4 channels combined in
Bridged/Parallel AB+CD,
Doubles current & voltage
8 
2500 1500 3500 2500 4200 4200
4 
3000 1600 4000 2500 7000 4500
2 
N/R
3
N/R
3
N/R
3
N/R
3
8000 4000
4 channels combined in Parallel
ABCD
Quadruples currenT
8 
800 400 1000 1000 1250 1250
4 
1250 800 2000 1600 2500 2400
2 
1700 1600 4000 2500 5000 4500
1 
2500 1500 4000 2000 7000 4500
1 Specifications are subject to change without notice.
2 Max Power
» Max Power data is based on the most potential any single amplifier channel can deliver. This data is most useful for asymmetrical loading of amplifier
channel and maximizing power utilization of the amplifier. When utilizing FlexAmp™ power requirements, be sure to take into consideration the
power capabilities of the channel AND the capabilities of the Power Supply.
» Continuous Power indicates amplifier output capabilities with all channels driven with the same load without exceeding the capabilities of the power
supply.
» Power Spec is based on 1 kHz, 20 msec
3 N/R = Not Recommended

QSC CX-Q Series Specifications

General

Dante	Yes
THD+N	<0.05%
DSP	Yes
Weight	Varies by model
Power Output	Varies by model
Frequency Response	20Hz - 20kHz (+0/-0.5dB)
Power per channel (8 ohms)	Varies by model
Power per channel (4 ohms)	Varies by model
Power per channel (2 ohms)	Varies by model
Bridged Mode	Yes
Height	2U
Protection	Thermal, short circuit, DC, overload
