3.2 Identication of parts
3.2.1 Angled (Default) Version
2
6
3
1
7
5
4
1 DS200 Folder/Inserter
2 Adjustable Roller Plate (see section 4)
3 Adjustable Backstop (see section 4)
4 Conveyor Surface
5 Conveyor Stand Unit
6 Adjustable Backrest (see section 4)
7 Operator Screen
