Quanmax KEMX-1750 series User Manual

Chapter 2
31
KEMX
-
1
7
50 serie
s
Use r’ s M a nual
Table 31 PEG1 PCIE Express x1 Slot
Pin Side
B
Side
A
1 +12V PRSNT1#
2 +12V +12V
3 Reserved +12V
4 Ground Ground
5 SMCLK Reserved
6 SMDAT Reserved
7 Ground Reserved
8 +3.3V Reserved
9 Reserved +3.3V
10 +3.3VSB +3.3V
11 WAKE# PERST#
12 Reserved Ground
13 Ground REFCLK+
14 HSOP0 REFCL
K
-
15 HSON0 Ground
16 Ground HSIP0
17 PRSNT2# HSIN0
18 Ground Ground
SLOT, DIP PCI 18*2P EXPRESS 180 D( F) Black
[ Win Win WPES--036AN41B22UWS] LEA D
FREE
Table 32 SATA1 Serial ATA Port 0 Connector
Pin Signal Name
1
GND
2
TX
+
3
TX
-
4
GND
5
RX
-
6
RX+
7
GND
DIP SATA-7P 180D CONN. BLU
E
/
double row
pin/parallel positioning peg [WIN WIN
WATM-07ABN4A2B8UW4]
