Table 47 Advanced Menu – Super IO Configuration
BIOS SETUP UTILITY
Mai n Adv an c ed Boot Security Save & Exit
Sup er IO Co nfig ur atio n
>Serial Port 1 Co nfig uratio n
>Serial Port 2 Co nfig uratio n
>Serial Port 3 Co nfig uratio n
>Serial Port 4 Co nfig uratio n
>Serial Port 5 Co nfig uratio n
>Serial Port 6 Co nfig uratio n
>Parallel Port C onfig ur ati on
  Select Screen
↑↓ Select It em
Enter: Sel ect
+- Chang e Op t.
F1: Ge neral H elp
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC E xit
Version 2.1 6. 124 2. C op yrig ht (C) 20 13, American M egatren ds, I nc.
Table 48 Advanced Menu – Super IO Configuration – Serial Port 1 Configuration
BIOS SETUP UTILITY
Mai n Advanced Boot Chipset Power Security Exit
Serial Por t 1 Co nfig ur atio n
Serial Port [Enabled]
Device Settings IO=3F8h ; IRQ=4;
Chang e Setti ng s [Aut o]
Serial Port 1 Type [RS232]
: Select Scree n
↑↓: Selec t It em
Enter: Sel ect
+/-: Chang e O pt.
F1: Ge neral H elp
F2: Previous Values
F3: Optimized Defaults
F4: S a ve an d E xit
ESC: E xit
Version 2.1 5. 122 6. C op yrig ht (C) 20 12 Am erican M eg atr ends , I nc.
Serial Port
Options: Disabled, Enabled
Change Settings
Options: Auto,
IO=3F8h; IRQ=4;
IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
Serial Port Type
Options: RS232, RS422, RS485
