Table 51 Advanced Menu – Super IO Configuration – Serial Port 4 Configuration
BIOS SETUP UTILITY
Mai n Advanced Boot Chipset Power Security Exit
Serial Por t 4 Co nfig ur atio n
Serial Port [Enabled]
Device Settings IO=2E8h ; IRQ=7;
Chang e Setti ng s [Aut o]
: Select Scree n
↑↓: Selec t It em
Enter: Sel ect
+/-: Chang e O pt.
F1: Ge neral H elp
F2: Previous Values
F3: Optimized Defaults
F4: S a ve an d E xit
ESC: E xit
Version 2.1 5. 122 6. C op yrig ht (C) 20 12 Am erican M eg atr ends , I nc.
Serial Port
Options: Disabled, Enabled
Change Settings
Options: Auto,
IO=2E8h; IRQ=7;
IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2F0h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2E0h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
