Table 49 Advanced Menu – Super IO Configuration – Serial Port 2 Configuration
BIOS SETUP UTI LITY
Main Advanced Boot Security Save & Exit
Serial Por t 2 Co nfig uratio n
Serial Port [Enabled]
Device Settings IO=2F8h; IRQ=3;
Chang e Setti ng s [Aut o]
Serial Port 2 Type [RS232]
  Select Screen
↑↓ Select It em
Enter: Sel ect
+- Chang e Op t.
F1: Ge neral H elp
F2: Previous Values
F3: Optimized Defaults
F4 Save & Exit
ESC E xit
Version 2.1 6. 124 2. C op yrig ht (C) 20 13, American M egatren ds, I nc.
Serial Port
Options: Disabled, Enabled
Change Settings
Options: Auto,
IO=2F8h; IRQ=3;
IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;
IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12
Serial Port Type
Options: RS232, RS422, RS485
