802BT/802R Video Test Generator User Guide 29
The table below provides a summary of display characteristics and the images used to
evaluate them. For details on the images and display attributes, see Appendix B, “Image
Reference.”
Display type Display test Recommended images
Analog CRT Geometry (pin and barrel,
linearity)
Static images
Hatch (TVHatch, Hatch_16, Hatch_20), Cir-
clesL, Geom_1 - Geom_5, SMPTE133
Focus Focus_@6, Focus_@7, Focus_@8,
Focus_@9, Text_9, Text_9T, Text_11,
Text_12T, Text_16
Photometry (chrominance,
contrast, levels)
Flat, Flat07, Flat13, Flat20, Flat27, Flat33,
Flat40, Flat47, Flat53, Flat60, Flat67, Flat73,
Flat80, Flat87, Flat93, FlatGray, Flat_01,
Flat_02, Flat_03, Flat_04, Flat_05, Flat_06,
Flat_07, Flat_08, Flat_09, Flat_10, Flat_11,
Flat_12, Flat_13, Flat_14, Flat_15, Flat_16,
Ramp_B, Ramp_G, and Ramp_R,
ColorBar, SMPTEbar, TVBar100 & TVBar_75
(TV formats only)
Luminance SMPTE133 (grayscale), Grays5, Grays9,
Grays11, Grays16, Grays32, Grays64
Gamma correction SMPTE133 (checkerbox)
Resolution BurstTCE, Burst (TV formats only), Grill_11,
Grill_15, Grill_22, Grill_33, Grill_44
Pulse (CE SDTV) PulseBar
Centering Outline0, Outline1, Outline2, Outline3
Voltage Regulation Regulate
Electromagnetic Interfer-
ence
EMITest1, EMITest2, EMITest3, EMITest4,
EMITest5
