Quantum Data 802BT - Lglcdtvb, Lglcdtvg, Lglcdtvr, Lglcdtvw

802BT/802R Video Test Generator User Guide 657
LGLCDTVB, LGLCDTVG, LGLCDTVR, LGLCDTVW
Description Special test image developed per customer specifications. Each image has three versions.
The primary version of the LGLCDTVB image is shown below.
LGRamp
Description Special test image developed per customer specifications. The image provides a
grayscale of two objects. The secondary version of the LGRamp image is shown below.
