Video Test Generator User Guide 575
CT
Audio coding type (see EIA/CEA-861-B standard, Table 19 for settings)
SS
Sample size (see EIA/CEA-861-B standard, Table 20 for settings)
SF
Sampling frequency (see EIA/CEA-861-B standard, Table 20 for settings)
MBR
Maximum bit rate (this setting multiplied by 8KHz represents the maximum bit rate of
the audio stream)
CA
Channel assignment code (see EIA/CEA-861-B standard, Table 22 for settings)
Note: Setting the XAUD:CA value will automatically set both DACA and DAXA to
corresponding values. See the table on page 271 to view these settings.
CT3 CT2 CT1 CT0 Audio Coding Type
0 0 0 0 Refer to Stream Header
0 0 0 1 IEC60958 PCM [26, 27]
0010 AC-3
0 0 1 1 MPEG1 (Layers 1 & 2)
0 1 0 0 MP3 (MPEG 1 Layer 3)
0 1 0 1 MPEG2 (multichannel)
0110 AAC
0111 DTS
1000 ATRAC
SS1 SS0 Sample Size
0 0 Refer to Stream Header
01 16 bit
10 20 bit
11 24 bit
SF2 SF1 SF0 Sampling Frequency
0 0 0 Refer to Stream Header
001 32 kHz
0 1 0 44.1 kHz (CD)
011 48 kHz
100 88.2 kHz
101 96 kHz
1 1 0 176.4 kHz
111 192 kHz
CA Channel Number
765432108 7 6 5 4 3 2 1
